OMICRON Repair Services India

OMICRON is a globally recognised Austrian manufacturer specialising in power systems testing, diagnostic software, and condition monitoring equipment for electrical utilities and industrial power networks. Their advanced testing solutions are deployed across transmission, distribution, and generation sectors worldwide. In India, OMICRON's relay testers, transient recorders, and power quality analysers are critical in substations managed by state electricity boards, private utilities, and large industrial facilities across Maharashtra, Gujarat, Tamil Nadu, and Andhra Pradesh.

OMICRON is a globally recognised Austrian manufacturer specialising in power systems testing, diagnostic software, and condition monitoring equipment for electrical utilities and industrial power networks. Their advanced testing solutions are deployed across transmission, distribution, and generation sectors worldwide. In India, OMICRON's relay testers, transient recorders, and power quality analysers are critical in substations managed by state electricity boards, private utilities, and large industrial facilities across Maharashtra, Gujarat, Tamil Nadu, and Andhra Pradesh.

Synchronics Electronics has built deep expertise repairing OMICRON's 18-product catalogue including relay test sets, fault locators, oscillography units, and communications modules. Our 180+ engineers understand OMICRON's proprietary firmware, high-voltage testing protocols, and signal conditioning architecture.

21
Products in Catalog
11+
Product Categories
6 Mo
Repair Warranty
32+
Years Experience
Repair Expertise

OMICRON Product Lines We Repair

Our engineers are trained on the full OMICRON product range. Below are the major product families we service.

CMC (Compact Measurement and Control)

Multifunction relay test set and power quality analyser for protective relay testing and power system commissioning. Common failures include capacitive touchscreen degradation, signal conditioning board noise coupling, and firmware corruption affecting waveform generation accuracy.

CMC356CMC357CMC366CMC356M

COMTRADE Data Acquisition & Transient Recording

Portable transient fault recorder for capturing waveforms during system disturbances. Repair issues include memory module failures, GPS synchronisation drift, and digital I/O card contact erosion from high-frequency switching transients.

RMC4RMC5COMTRADE Logger

PROTECTION SUITE Software & Hardware Interface

Software-based relay setting analysis and IED configuration platform with Ethernet/serial communication modules. Common faults include USB-to-serial adapter failures, incompatible driver installation causing communication timeouts, and SD card file system corruption.

PROTECTION SUITE License Key ModuleCommunication Interface ModuleIED Gateway

Transient Fault Locator (TFL)

Portable fault location tool using travelling wave detection on transmission lines. Typical failures: GPS antenna connector corrosion, battery charging circuit degradation, and RF interference in signal conditioning amplifiers causing false distance calculation.

TFL-1TFL-2TFL-2E

Power Quality Analyser (PQM)

Three-phase voltage and current quality monitoring with harmonic analysis and event logging. Repair challenges include current transformer signal clipping, voltage divider resistor drift affecting RMS accuracy, and flash memory wear from continuous data logging.

PQM-1PQM-2PQM-3

Test Lead & Probe Assemblies

High-voltage test leads, safety interlocks, and current injection probes for field testing. Common issues: insulation degradation at stress relief points, connector pin pitting from arcing, and mechanical wear in spring-loaded alligator clamps.

HVL300CLP800SIU3
Why Us

Why Choose Synchronics for OMICRON Repairs?

🔬

PCB-Level Expertise

We repair down to the component level — not just swap boards. Our engineers identify root causes, replace failed IGBTs, capacitors, processors, and gate drivers on OMICRON equipment.

⚡

Fast Turnaround

Standard 7–10 working days. Express 3–5 days available for critical breakdowns. Emergency same-day/next-day service for unplanned downtime.

🛡️

6-Month Warranty

Every repaired unit ships with a 6-month comprehensive warranty on parts and labour. Our repair success rate is over 94% across all brands.

📦

All-India Service

Couriered repairs accepted from any city in India — Vadodara, Mumbai, Pune, Ahmedabad, Surat, Chennai, and more.

Diagnosis

Common OMICRON Equipment Faults We Fix

Based on 30+ years of repair data, these are the most frequent failure modes we see in OMICRON equipment arriving at our workshop.

  • ✓Waveform generation distortion in CMC relay testers — OMICRON CMC356/357 units suffer harmonic injection errors when output D/A converter capacitors degrade or when the internal waveform memory becomes corrupted from sudden power loss during test cycles. This causes relay protection settings to be misjudged during acceptance testing.
  • ✓GPS time synchronisation loss in transient recorders — OMICRON RMC4/RMC5 units lose GPS lock when antenna connectors corrode (common in coastal Indian substations), when firmware NTP polling fails, or when the real-time clock battery (typically 10-year coin cell) reaches end of life. This invalidates timestamp correlation during multi-site fault analysis.
  • ✓USB/Serial communication timeout errors — OMICRON PROTECTION SUITE communication modules and CMC units fail to establish handshakes when the onboard USB-to-UART bridge (FTDI or SiLabs chipset) develops cold solder joints under thermal cycling, or when older units experience driver incompatibility with Windows 10/11 systems.
  • ✓Current transformer signal clipping in PQM power quality analysers — OMICRON PQM-1/2 units clip or saturate AC signal inputs when CT secondary burden increases (due to extended cable runs in retrofit installations) or when internal signal conditioning amplifiers develop offset bias. This renders harmonic analysis unreliable, showing erroneous THD and individual harmonic component readings.
  • ✓Travelling wave transient detector desensitisation — OMICRON TFL-1/TFL-2 fault locators lose sensitivity to fault transients when RF shielding degrades in the signal conditioning enclosure, when the dV/dt detection amplifier develops excess noise floor, or when GPS/sampling clock synchronisation drifts. Fault location distance accuracy degrades to ±5-10% instead of ±1-2%.
  • ✓Test lead and probe insulation breakdown — OMICRON high-voltage test leads (HVL300) and current injection probes (CLP800) develop partial discharge and arcing when outer silicone insulation cracks at stress relief points, or when internal wire strands corrode from moisture ingress. This creates safety hazards and measurement errors during field testing at 10-66 kV substations.
Process

How We Repair Your OMICRON Unit

📥
Step 1

Receive & Log

Your unit is logged into our tracking system with a unique job number. You receive WhatsApp / email updates at every stage.

🔬
Step 2

Fault Diagnosis

Board-level diagnosis using oscilloscopes, LCR meters, and thermal cameras. Root cause identified before any repair begins.

🔧
Step 3

Component Repair

Faulty ICs, capacitors, MOSFETs, IGBTs, and gate drivers replaced with genuine or equivalent-spec components.

✅
Step 4

Full-Load Test

Unit tested under rated load with original or equivalent motor. All parameters verified. 6-month warranty issued.

Sectors

Industries Using OMICRON Equipment

We serve plant maintenance teams across all major industries where OMICRON automation is deployed.

State and Private Electricity Distribution (DISCOMS)Power Transmission Utilities and Regional Load Despatch CentersRenewable Energy (Solar and Wind Farm Substations)Oil and Gas Refining and Petrochemical PlantsSteel and Aluminium ManufacturingRailway Traction Power SupplyData Center Power InfrastructureCement and Heavy Manufacturing
FAQ

Frequently Asked Questions — OMICRON Repairs

Is Synchronics an authorised OMICRON service centre?+

No. Synchronics Electronics Pvt. Ltd. is an independent third-party repair provider. We are not affiliated with, authorised by, sponsored by or endorsed by OMICRON or its group companies, and we are not an official OMICRON service centre, dealer or representative. Brand names and model numbers are used only to identify the equipment we repair. If your equipment is under manufacturer warranty or a service contract, please contact the manufacturer first — third-party repair may affect that cover.

Do you repair OMICRON equipment anywhere in India?+

Yes. Synchronics repairs the complete OMICRON 18-product range — CMC relay testers, transient recorders, TFL fault locators, power quality analysers, and all accessories. All repairs and testing are performed in our Vadodara, Gujarat facility with 48-72 hour turnaround on most units.

What is the typical repair cost and timeline for an OMICRON relay tester displaying 'Waveform Memory Error'?+

Synchronics provides free diagnostics (48 hours) to confirm the exact fault and quote accurately before you authorise repair.

Do you stock OMICRON spare parts for emergency repairs?+

Synchronics maintains inventory of critical OMICRON components including USB-to-serial bridge modules, waveform ROM chips, GPS antenna connectors, signal conditioning amplifiers (OPA2134, OPA2333 series), and high-voltage test lead replacements. We also hold refurbished test probe assemblies (HVL300, CLP800, SIU3) for rapid swap-out. Contact our dispatch team for real-time spare parts availability.

How do I send my OMICRON unit for repair?+

Pack the unit securely and courier it to our Vadodara workshop. Include a note with the fault description and your contact details. We will log it into our system and WhatsApp you a job number within 24 hours of receipt.

What is the cost of repairing a OMICRON drive or PLC?+

Repair cost depends on the model and the fault. We offer a free diagnosis — once we identify the fault, we provide a fixed quotation before proceeding. Typical repairs cost 20–40% of the new unit price. We will never repair without your approval.

What warranty do you provide on OMICRON repairs?+

All repaired units carry a 6-month comprehensive warranty covering the same fault and related issues. If the fault recurs within the warranty period, we repair it free of cost.

Do you provide a no-fix, no-fee guarantee?+

Yes. For standard units, evaluation is free and included in the repair cost — if we cannot repair your OMICRON unit, no repair charge is raised. A physical inspection charge applies only if the unit has already been subjected to a third-party repair attempt, and we tell you before we start.

OMICRON Repair Catalog

Showing 1–21 of 21 OMICRON products

ANALYZER CURRENT TRANSFORMER TEST KIT CPC 100

ANALYZER CURRENT TRANSFORMER TEST KIT CPC 100

260085

Current Transformer Testing and Analysis Equipment

32+
Years in Business
80,000+
Units Repaired
150+
Workstations
4.8★
682 Reviews

Disclaimer

OMICRON and all associated product names and model numbers are trademarks of their respective owner(s). Synchronics Electronics Pvt. Ltd. is an independent third-party repair provider and is not affiliated with, authorised by, sponsored by or endorsed by OMICRON. Product names and model numbers are used solely to identify the equipment on which repair services are offered, and no trademark ownership is claimed or implied.
